Installation and Commissioning — Mini Touch

Installing the AG Angle Valve

1. Open the cold water supply at the angle valve under the sink.
2. Unscrew the hose connecting the faucet to the angle valve under the sink.
3. Insert the angle valve at this point and tighten it.
4. Screw the faucet hose back onto the angle valve.
5. Insert the supplied 1/4 inch blue PE hose into the AG angle valve.
6. Now tighten the nut to secure the PE hose.

Installing the Drain Clamp

Attach the supplied drain clamp with the black square gasket just above the siphon (A) of the drain pipe.

1. Stick the supplied gasket onto the drain pipe and drill a hole with a 6mm drill bit.
2. Screw in the fitting and place the drain clamp centered over the drilled hole, then tighten it.
3. Insert the supplied white hose until it clicks into place.

Installing the DM Pre-filter

Insert the supplied pre-filter (A) between the AG angle valve (B) and the appliance (C). Simply cut the blue PE hose anywhere and place the pre-filter in between. Make sure to observe the direction of the arrow.

Connecting the Hoses to the Mini Touch and Opening the Water Supply

1. Remove the two protective caps on IN (A) and OUT (B) (press the safety ring and remove the caps).
2. Insert the blue hose into the IN (A) connection (coming from the AG angle valve).
3. Insert the white hose into the OUT (B) connection (coming from the drain clamp).
4. Pull on the hoses several times to ensure they are securely fastened in the connections.
5. Open the angle valve (C) under the sink again.
6. Make sure the AG angle valve (D) is also open.
7. Plug the power cord into the socket.

End of Installation

After successful installation, the appliance automatically switches to cleaning mode. The filtration indicator (Filtration) lights up continuously on the screen during this time. As soon as the cleaning mode is finished, the appliance automatically switches to filtration mode until the internal clean water tank is full. This process takes about 10-15 minutes.

Important Notes on Hot Water Use

• Before using the "HOT," "TEA," and "BABY" temperatures, it is important that the system is filled with water.
• When first switched on or after a restart, the appliance produces water at room temperature for the first 60 seconds. Hot water is only available after this time.
• The baby function is equipped with an automatic shut-off device. In hot weather, if the ambient temperature is high, the baby function may deactivate for safety reasons. In this case, use the TEA and ROOM buttons to maintain the desired temperature.

Before First Use

1. After installation, wait until the filtration light turns off, then place a glass under the outlet. Press the ROOM button several times (up to 5 times) until water flows.
2. Empty the internal tank by placing a sufficiently large container under the water outlet, then pressing and holding the ROOM and TEA buttons for about 6 seconds.
3. Empty the water until no more flows and the filtration symbol flashes. The appliance automatically starts filtering water again until the internal tank is full.
4. If the taste of the water changes, take approximately 200 ml of hot water (HOT) to sufficiently rinse the filters, the instantaneous water heater, and the tank.
